CovMesh Belt Tunnel Freezeryog tsim los rau cov khoom uas xav tau kev khov kho tas li ntawm qhov muaj zog thiab huv si conveyor nto. Stainless hlau mesh siv txhawb nqa cov khoom thaum huab cua txias circulates los ntawm lub qhov, pab ua kom tsis txhob khov rau cov nqaij nruab deg, nqaij, pasta, khoom noj bakery, thiab npaj zaub mov.
Lub freezer no feem ntau xaiv thaum cov khoom tsis tshua muaj me me los yog kua dej tab sis tseem xav tau kev txav mus los thiab txhim khu kev qha txias txias - huab cua sib cuag. Txoj siv dav dav, qhov ntev, qhov dav dav, thiab lub sijhawm khov tuaj yeem hloov kho raws li lub peev xwm, cov khoom tuab, thiab lub hom phiaj tseem ceeb ntawm qhov kub thiab txias.
Technical Parameters
|
Qauv |
Peev xwm (kg / h) |
Lub sijhawm khov (min) |
Cua txias (kW) |
Lub cev muaj zog (kW) |
Lub Freezing Room L × W × H (m) |
Zuag qhia tag nrho L × W × H (m) |
Circulating Temp. (degree) |
|
SSD-300S |
300 |
3–50 |
70 |
15.5 |
13×2.5×1.6 |
17×2.5×2.2 |
−36±2 |
|
SSD-400S |
400 |
3–50 |
110 |
17.5 |
15×2.5×1.6 |
19×2.5×2.2 |
−36±2 |
|
SSD-500S |
500 |
5–60 |
130 |
20.5 |
18×2.5×1.6 |
22×2.5×2.2 |
−36±2 |
|
SSD-600S |
600 |
5–60 |
160 |
22 |
20×2.5×1.6 |
24×2.5×2.2 |
−36±2 |
|
SSD-700S |
700 |
5–60 |
190 |
26 |
22×2.5×1.6 |
26×2.5×2.2 |
−36±2 |
|
Qauv |
Peev xwm (kg / h) |
Lub sijhawm khov (min) |
Cua txias (kW) |
Lub cev muaj zog (kW) |
Lub Freezing Room L × W × H (m) |
Zuag qhia tag nrho L × W × H (m) |
Circulating Temp. (degree) |
|
SSD-300K |
300 |
3–60 |
70 |
17 |
8×3.0×1.6 |
10.4×3.0×2.5 |
−36±2 |
|
SSD-500K |
500 |
3–60 |
130 |
18 |
9×3.0×1.6 |
12.4×3.6×2.5 |
−36±2 |
|
SSD-1000K |
1000 |
3–60 |
186 |
22 |
11×3.0×1.6 |
14.9×3.6×2.5 |
−36±2 |
|
SSD-1500K |
1500 |
6–80 |
256 |
25 |
13×3.0×1.6 |
16.9×3.6×2.5 |
−36±2 |
|
SSD-2000K |
2000 |
6–80 |
330 |
28 |
16×3.0×1.6 |
19.9×3.6×2.5 |
−36±2 |
|
SSD-3000K |
3000 |
6–80 |
550 |
35 |
18×3.0×1.6 |
21.9×3.6×2.5 |
−36±2 |
Khoom nta
• Mesh siv txoj siv sia txhawb kev tu yooj yim thiab ua haujlwm ntev - tu cev.
• Stable conveying yog haum rau ntau yam zoo li tus thiab semi-processed khoom.
• Nruam khov kho txhim kho kev ua haujlwm ntau lawm piv nrog batch khov.
• tuaj yeem txuas nrog kev ntxuav, blanching, txias, txheej, lossis cov kab ntim khoom.
Q&A
Q: Kuv yuav tsum muab cov ntaub ntawv dab tsi los xaiv lub tshuab haum?
A: Koj yuav tsum qhia peb txog koj qhov kev faib khoom, qhov loj me, cov khoom siv ntsuas kub, lub hom phiaj kub tom qab ua tiav, lub peev xwm tuav ib teev thiab kev tsim qauv tsim.
Q: Puas muaj kev xaiv los kho lub tshuab?
A: Customization muaj. Peb tuaj yeem kho lub tshuab qhov ntev, dav, qhov siab conveyor, lub zog hluav taws xob, khoom noj khoom haus sib cuag thiab txoj kev sib txuas kom phim koj cov kav dej.
Q: Chav tsev no puas tuaj yeem ua haujlwm hauv cov chaw tsim khoom noj khoom haus?
A: Nws yog tsim rau cov khoom noj khoom haus ib puag ncig nrog tag nrho stainless hlau thav duab ua raws li cov qauv kev nyab xeeb khoom noj. Kev ntxuav cov kab tuaj yeem ua kom zoo rau koj qhov kev teeb tsa kev cob qhia.
Q: Cov khoom no puas tuaj yeem txuas rau lwm lub tshuab ua haujlwm?
A: Nws tuaj yeem txuas seamlessly nrog ntxuav, blanching, txias, ziab, khov, sorting thiab ntim iav los tsim ib tug tas mus li qhov kawg - mus rau - kawg ua kab.
